Butyl Rubber
Isobutylene Isoprene Rubber (IIR) — the most gas-impermeable synthetic rubber available. Exceptional chemical resistance, vibration damping, and weather durability.
Seals That Never Leak
Butyl Rubber's near-zero gas permeability and outstanding chemical resistance make it irreplaceable in applications demanding airtight performance and long-term durability.
Unmatched Gas Impermeability
The lowest gas permeability of any commercial rubber. Essential for tyre inner tubes, tubeless liners, inflatable bladders, and gas-tight seals.
Chemical Resistance
Excellent resistance to acids, alkalis, and oxidizing agents. Suitable for pharmaceutical, chemical processing, and industrial sealing applications.
Weather & Ozone Resistance
Maintains integrity under UV exposure, ozone, and extreme temperatures. Preferred for roofing membranes, window seals, and outdoor applications.
Vibration Damping
Superior energy absorption and dissipation properties. Ideal for shock absorbers, engine mounts, vibration dampers, and noise-reduction systems.
Electrical Insulation
Good dielectric properties for cable insulation, electronic enclosure gaskets, and high-voltage applications requiring non-conductivity.
Flexibility & Elasticity
Highly flexible and elastic under repeated stretching and bending. Maintains shape and performance throughout extended service life.
Where Butyl Rubber Excels
Tyre Inner Tubes & Liners
The primary application of Butyl Rubber globally. Near-zero air permeability keeps tyres inflated longer, improving safety and fuel efficiency.
Seals & Gaskets
Airtight and chemical-resistant seals for automotive, pharmaceutical, and industrial equipment. Window seals, door gaskets, and O-rings.
Roofing & Waterproofing
EPDM/Butyl roofing membranes, pond liners, and waterproofing sheets. Outstanding weather resistance for decades of outdoor service.
Vibration Isolation
Engine mounts, shock absorbers, anti-vibration pads, and acoustic damping. Absorbs and dissipates mechanical energy efficiently.
Key Properties
Core specifications for Butyl Rubber. For full technical data — see the Technical Data Sheet.
| Polymer Type | Isobutylene Isoprene Rubber (IIR) |
| Specific Gravity | 0.91 – 0.92 |
| Mooney Viscosity | 50 – 55 ML (1+8) @ 125°C |
| Unsaturation | 0.6 – 2.5 mol% |
| Tensile Strength | 10 – 17 MPa (compounded) |
| Service Temp Range | −45°C to +120°C |
Compounds with Confidence
Butyl Rubber processes on standard rubber mixing equipment. Can be cured with sulfur or resin systems. Blends with EPDM, NR, and halobutyl rubber.
Store in cool, dry conditions away from direct sunlight and heat. Keep bales in original Reliance packaging on pallets. Shelf life: 12 months from manufacture.
Need Butyl Rubber?
Get competitive pricing, grade selection support, and rapid dispatch from our Reliance-approved stocking points across Telangana & AP.
